CAT 6 CAT 5 Rj45 Data Socket Silver / Black / Grey / Champagne
Premium Products
CAT 6 CAT 5 Rj45 Data Socket Silver / Black / Grey / Champagne
1
2
Brand Name :Smart Laffey
Model Number :ST-DATA-HR7
Place of Origin :Guangdong, China
MOQ :50 Pieces
Price :Negotiable
Supply Ability :20000 Piece/Pieces per Month
Delivery Time :10-15 work days
Packaging Details :Carton Box
Name :Media Data Socket
Type :RJ45 CAT5 / CAT6
Color :Silver / Black / Grey / Champagne
Material :HR7 aluminum
Function :Connect Data
Standard :UK standard
Contact Now
Home / Hotel Media Data Socket RJ45 CAT 5 Grey / Silver Color
Specifications
Product Name
Media Data Socket
Brand
Smart Laffey
Size
86mm*86mm
Color
Silver / Black / Grey / Champagne
Back Box for Installation
UK Square Box
Application
Hotel / Home / Villa
Product Features
1. The H platform is an upgraded version of the G platform with larger functional modules.
2. Variety color frame and module: The color of the frame is generally matched with the color of the module, except for the rose gold which is equipped with a black module.
3. Standard 86 wall box installation, multiple panels can connect seamlessly.
Description
This product is assembled from an eight-core computer socket module, which has the advantages of small size and superior performance. The connector uses a QuickPort embedded module with excellent performance. It can meet the requirements of ELA/TLA568B for CAT 5 connection hardware performance, and the transmission rate is up to 115MHZ.
Installation Method
1. Connection according to connection diagram
2. Dissemble the frame
3. Dissemble the right and left key cover and expose the hole for fix.
4. Put the screw into the hole and screw in with torque 0.2-0.4N.m (2.0-4.0kgf.cm) fixing the switch
5. Assemble the key cover and frame
No need to dissemble key cover under following condition:
1. Fix hole is exposed out of key cover.
2. Using additional hole to fix
Advantages
(1) Mutual benefit : We are factory also have more than 10 years experience in manufacturing and developing of switches and sockets.
(2) Customize : We have strong R&D team, we will try our best to custom product as your request.
(3) OEM service : (a) Printing your Logo (b) Engraving words or icons
(4) Mix order : We accept mix order, different model and small quantity order.
FAQ
1. Q:What’s the shipping method?
A: By express way. Such as Fedex, DHL, TNT and so on; by air or by sea. Shipping cost is decided by shipping ways and product’s actual weight and volume, also your detailed address.
2. Q:Can we print our own brand or logo on your products?
A:Yes, it is our pleasure to be one your OEM manufacturer in China to meet your OEM requirements.
3. Q: Why do some goods have difference between website picture and practical items?
A:Because difference of light and browser, also different batches, materials may be little difference, such as lining. Sometimes, the picture is for reference only. These are allowed in actual case. If any question, please tell us before order and ask clearly.
4. Q: Can I order one piece for sample or trial order less than MOQ to test the quality?
A: Yes, We recommend to check the sample before order. We accept trial order less than MOQ.
5. Q: If I order big quantity, what's the good price?
A: Please send the details enquiry to us, such as the Item Number, Quantity for each item, Quality request, Logo, Payment Terms, Transport method, Discharge place etc. We will make the accurate quotation to you as soon as possible.
If you have another question, please feel free to contact us.
